Midea 4 Way Cassette Split Air Conditioner Universal Wired Controller Remote Control for Hotel Office

Midea 4 Way Cassette Split Air Conditioner Universal Wired Controller Remote Control for Hotel Office

4 Pipe Fan Coil Thermostat used for central air conditioning system, used to control fan coil. The thermostats has 3 fan speed choice. It has Wi-Fi and without Wi-Fi type.

Send Inquiry
Product Introduction

Through independent innovation, we have made every effort to develop new External Floor Temperature Sensor, OLED Screen Display Radiator Actuator, floor heating controller for 8 channels, giving new connotation and vitality to the traditional products. In the production process, our company has been 'people-oriented, excellence' as the criterion, strict quality control. We always take quality enterprise and innovation leading as the main line of work, and work hard in the development of standards and new technologies. In the development process, the company adheres to the aerospace spirit of "safe, reliable, and foolproof", always adheres to the highest product quality standards, and has established a complete quality assurance system.

Products Description



Our TDS21-AC Fan Coil Thermostat is for central air conditioning control system. It can control the on-off, fan speed of fan coils, mainly using for hotel and multi-unit residential buildings. It has cooling and heating function for different usage during winter and summer. In addition, our TDS21-AC has 4 periods time on-off funtion to make sure the convenient using of our users. It is also eay to install and maintain. It also has Wi-Fi model for option.



21-AC fan coil thermostat



Video



Technical Parameters



Feature Technical Parameter
Application Fan Coil Cooling and Heating System
Control Objects Fan Coil; Valves
Mode Timer On/OFF Automatically or Manul Mode
Power Supply 220Vac~240Vac
Current Load ≤5A
Temperature Set Range 10-40℃
Fan Speed Mode High/Mid/Low 3 Fan Speed Mode
Install Way Wall Insert
WiFi APP Beok AC






Thermostat Functions

Phone Control

The Wi-Fi model thermostat can be controlled by our BEOK AC application.

3 Fan Speed+Auto

Thermostat has 3 fan speed control function, Low, Mid, High 3 speed for option.

Fan Coil Control

Thermostat has fan coil in-control and out-of-control adjustable.

Timing Switch

Thermostat has programmable timing switch function, 4 period a day setting.



21WIFI-AC thermostat



Model Spec
wire connection of 2 or 4 pipe thermostat

TDS21-AC2

2 pipe thermostat



TDS21WIFI-AC2

Wi-Fi 2 pipe thermostat

AC-2pipe
AC-4pipe

TDS21-AC4

4 pipe thermostat

TDS21WIFI-AC4

Wi-Fi 4 pipe thermostat

Model Name TDS21-AC2 TDS21WIFI-AC2 TDS21-AC4 TDS21WIFI-AC4
Current Load 3~5Amp 3~5Amp 3~5Amp 3~5Amp
Power Voltage 200-240V 200-240V 200-240V 200-240V
Wi-Fi Function × √ × √
Pipe Type 2 pipe 2 pipe 4 pipe 4 pipe
Sensing Element NTC NTC NTC NTC



FAQ



Q: What is the diffreent between TDS21-AC4 and TDS21-AC2?

A: TDS21-AC4 is 4 pipe fan coil thermostat, that means it can control 2 valves so that the heat water and cold water can flow in different tube. TDS21-AC2 is 2 pipe fan coil thermostat, that means it can control 1 valve so that the heat water and cold water can flow in same tube. Therefore, their wire connection is different.

Q: Can I customize 24V TDS21-AC2 fan coil thermostat?

A: Yes, we support customization of 24V products, and the MOQ should be 300 pieces.

Q: How long is the quality guaranty period for your TDS21-AC thermostat?

A: The warranty time of all our thermostats are same, they all have 24 months warranty. During the period, if there is any unqualified, we can fix or replace for customers, although that is not happen oftenly.

Q: Which shipment method that I can choose if I buy your products?

A: We support Express like Fedex, UPS and DHL, Air shipping, Sea Shipping, Truck Shipping and other ways. We will choose the best way based on the order quantity, dimension, gross weight and shipping address area for customers based on our over 12 years export experience.

Q: Which color of TDS21-AC I can choose?

A: Our TDS21-AC has 2 colors of the frame, white and black for option; and the display screen light has white and blue color for option. Client can choose the prefer color and we can customize it by following their requirements.



Manual

product-90-90

White Screen 2 Pipe and 4 Pipe Fan Coil Thermostat TDS21-AC
