Pure White/Black Color Intelligent Zigbee Protocol Room Thermostat TDR89-ZB
video
Pure White/Black Color Intelligent Zigbee Protocol Room Thermostat TDR89-ZB

Pure White/Black Color Intelligent Zigbee Protocol Room Thermostat TDR89-ZB

Application: 16A/3A underfloor heating system
Features: Support Zigbee Gateway; week program
Model: EP or WP
EP is for 16A electric underfloor heatng
WP is for 3A water underfloor heatng

Send Inquiry
Download
  • Fast Delievery
  • Quality Assurance
  • 24/7 Customer Service

Shanghai Beok Controls Co., Ltd. is one of the most reliable manufacturers and suppliers of pure white/black color intelligent zigbee protocol room thermostat tdr89-zb in China. Our factory offers high quality products made in China with competitive price. Welcome to contact us for free sample and cheap products.



Products Description



TDR89 Zigbee Protocol Room Thermostat is used for underfloor heating system, including TDR89-ZB-EP thermostat for 16a electric underfloor heating system, TDR89-ZB-WP for 3a water underfloor heating system.



TDR89 Zigbee Room Temperature Controller can be connected with zigbee hub, then the user can linkage all the zigbee devices through the hub and control them via smart phone.



TDR89 Zigbee Smart Temperature Regulator is a touch screen product with rich features that includes weekly programmable (auto) function, child lock function, adjustable brightness, anti-frost function,etc. This temperature controller is available in black and white.



Zigbee underfloor heating thermostat



Technical Parameter



Current Load

≤ 16Amp

≤ 3Amp
Power Supply 100~240VAC, 50~60Hz
Electric Energy Consumption < 1Watt
Temp. Setting Range 5~95 Celsius
Temperature Accuracy +/-0.5 Celsius
Sensing Element NTC
Product Size 86*86*14mm
Product Material Anti-flammable PC
Ambient Temperature 0~45℃, 5~95％RH(Non-condensing)
Storage Temperature
-5~55℃
Timing Error < 1%
Installation Hole distance 60mm (suit for Europe standard size mounting box)





Zigbee floor heating thermostat



Model Spec



Model Name TDR89W(B)-ZB-EP TDR89W(B)-ZB-WP
Wiring Diagram

electrical floor heating Zigbee thermostat



Zigbee water underfloor heating thermostat


Current Loading 16 Amps 3 Amps
Sensors External floor sensor + Inner air sensor Inner air sensor only
Gateway Tuya Zigbee Gateway Needed Tuya Zigbee Gateway Needed





Manual
