White Screen 2 Pipe and 4 Pipe Fan Coil Thermostat TDS21-AC

White Screen 2 Pipe and 4 Pipe Fan Coil Thermostat TDS21-AC

Name: China White Screen 2 Pipe and 4 Pipe Fan Coil Thermostat TDS21-AC Suppliers, Factory - Free Sample - Beok
Brand: Beok Controls
SKU: 161491599

Application: for Central Air Conditioning System
Model: AC2 or AC4 optional
AC2-2 pipes fan coil
AC4-4 pipes fan coil

Send Inquiry

BEOK TDS21WIFI-AC Room Thermostat

Fast Delievery
Quality Assurance
24/7 Customer Service

Shanghai Beok Controls Co., Ltd. is one of the most reliable manufacturers and suppliers of white screen 2 pipe and 4 pipe fan coil thermostat tds21-ac in China. Our factory offers high quality products made in China with competitive price. Welcome to contact us for free sample and cheap products.

Products Description

Our TDS21-AC Fan Coil Thermostat is for central air conditioning control system. It can control the on-off, fan speed of fan coils, mainly using for hotel and multi-unit residential buildings. It has cooling and heating function for different usage during winter and summer. In addition, our TDS21-AC has 4 periods time on-off funtion to make sure the convenient using of our users. It is also eay to install and maintain. It also has Wi-Fi model for option.

21-AC fan coil thermostat

Video

Technical Parameters

Feature	Technical Parameter
Application	Fan Coil Cooling and Heating System
Control Objects	Fan Coil; Valves
Mode	Timer On/OFF Automatically or Manul Mode
Power Supply	220Vac~240Vac
Current Load	≤5A
Temperature Set Range	10-40℃
Fan Speed Mode	High/Mid/Low 3 Fan Speed Mode
Install Way	Wall Insert
WiFi APP	Beok AC

Thermostat Functions

Phone Control

The Wi-Fi model thermostat can be controlled by our BEOK AC application.

3 Fan Speed+Auto

Thermostat has 3 fan speed control function, Low, Mid, High 3 speed for option.

Fan Coil Control

Thermostat has fan coil in-control and out-of-control adjustable.

Timing Switch

Thermostat has programmable timing switch function, 4 period a day setting.

21WIFI-AC thermostat

Model Spec

wire connection of 2 or 4 pipe thermostat

TDS21-AC2

2 pipe thermostat

TDS21WIFI-AC2

Wi-Fi 2 pipe thermostat

TDS21-AC4

4 pipe thermostat

TDS21WIFI-AC4

Wi-Fi 4 pipe thermostat

Model Name	TDS21-AC2	TDS21WIFI-AC2	TDS21-AC4	TDS21WIFI-AC4
Current Load	3~5Amp	3~5Amp	3~5Amp	3~5Amp
Power Voltage	200-240V	200-240V	200-240V	200-240V
Wi-Fi Function	×	√	×	√
Pipe Type	2 pipe	2 pipe	4 pipe	4 pipe
Sensing Element	NTC	NTC	NTC	NTC

FAQ

Q: What is the diffreent between TDS21-AC4 and TDS21-AC2?

A: TDS21-AC4 is 4 pipe fan coil thermostat, that means it can control 2 valves so that the heat water and cold water can flow in different tube. TDS21-AC2 is 2 pipe fan coil thermostat, that means it can control 1 valve so that the heat water and cold water can flow in same tube. Therefore, their wire connection is different.

Q: Can I customize 24V TDS21-AC2 fan coil thermostat?

A: Yes, we support customization of 24V products, and the MOQ should be 300 pieces.

Q: How long is the quality guaranty period for your TDS21-AC thermostat?

A: The warranty time of all our thermostats are same, they all have 24 months warranty. During the period, if there is any unqualified, we can fix or replace for customers, although that is not happen oftenly.

Q: Which shipment method that I can choose if I buy your products?

A: We support Express like Fedex, UPS and DHL, Air shipping, Sea Shipping, Truck Shipping and other ways. We will choose the best way based on the order quantity, dimension, gross weight and shipping address area for customers based on our over 12 years export experience.

Q: Which color of TDS21-AC I can choose?

A: Our TDS21-AC has 2 colors of the frame, white and black for option; and the display screen light has white and blue color for option. Client can choose the prefer color and we can customize it by following their requirements.
